20W built-in speaker

Reference : IW-165 FTPC
SKU : 00090
EAN13 : 3701567905520

6" recessed ceiling speaker

20 - 15 - 10 - 5W

100V line

2-way coaxial

Colour: white

Power output
Share

Description

HIFI-quality rectangular in-ceiling speaker for in-wall installation

6-point locking system (anti-theft system) with back box

Equipped with a 16 cm Ø woofer, an eyeball tweeter, a 100 V line transformer with power adjustment by means of a switch on the front panel.

Product Details

  • Brand
  • Reference
    IW-165 FTPC
  • SKU
    00090
  • EAN13
    3701567905520

Data sheet

  • Type
    Ceiling speaker
  • Subject
    ABS + metal grille
  • 100 V line impedances
    500 / 670 / 1 / 2 K
  • Loudspeakers
    Woofer Ø 16 cm + tweeter
  • Sound pressure level
    87 dB / 1 W / 1 m
  • Bande passante
    50 – 20 000 Hz
  • Puissance ligne BI
    8 Ω– 20 W RMS
  • Puissance ligne 100 V
    20 - 10 - 5 W RMS
  • Diamètre encastrement
    270 mm
  • Connections
    Sur borniers poussoirs
  • Dimensions (W × D × H)
    307 x 220 x 110 mm
  • Weight
    2,9 kg
