Amplifier - preamplifier with network adapter IP 350W

Name: Amplifier - preamplifier with network adapter IP 350W
Brand: RONDSON
SKU: AM 350 IP

Reference : AM 350 IP

SKU : 02119

EAN13 : 3701567910425

Mixing amplifier on IP 350W

Power output

350 W

Sonorisation sur IP

Amplificateurs mélangeurs sur IP

Download (5.14MB)

AM 350 IP

Download (356.1KB)

Description

Description :

This 350 W RMS amplifier-preamplifier is equipped with an IP network adapter (1).
It offers 100 V and 70 V loudspeaker outputs as well as 4-16 Ω (in Low Impedance).
It operates on a 230 V mains supply.

It works exclusively with the IP AM IP SOFTWARE software.
(1) Internet protocol (abbreviated to IP)

Characteristics :

High quality TCP/IP digital audio transmission, without interference
LCD display, all functions can be activated with a single button
Free digital audio control, multi-function combination and partition, local broadcast function
Built-in alarm cut-off function, no forced cut-off 24V, not limited to the amount of volume settings, 3-line connection
Power management, when there is no music or calls the unit goes into standby mode automatically.
Standby consumption is less than 3%, which corresponds to energy saving standards.
Each MIC, AUX and network source has an individual volume control.
Line out for extension
6 output level indicators
Progressive fan cooling function
Speaker output 70V and 100V or 4 and 16 Ω

SPECIFICATIONS	AM 350 IP
Type	Amplifier Preamplifier with IP network adapter
Output power	350 W RMS
Power supply	AC 230V
Speaker outputs	70 and 100V , 4-16 Ω
Internet socket	RJ 45
Transmission speed	10 Mbps
Support	TCP / IP, UDP, IGMP (group broadcast)
Sound format	MP3 / MP2
Sound quality	16-bit stereo CD quality
Sampling	8 K - 48 K
Capacity	8 K - 512 kbps
Inputs/Sensitivity	MIC : 5 mV AUX : 350 mV
Frequency Response	60 Hz – 18 000 Hz (± 3 dB)
Signal-to-noise ratio	≥ 65 dB
Consumption	350 W
Total harmonic distortion	<0,1%
Protection and cooling	Fan, Thermal protection, overload and short-circuit
Dimensions (W x D x H)	484 x 359 x 132 mm - 19" - 3U
Weight	16 kg
