500W amplifying matrices of 2 zones in 100V

Name: 500W amplifying matrices of 2 zones in 100V
Brand: RONDSON
SKU: AM-2500-2

Reference : AM-2500-2

SKU : 02694

EAN13 : 3701567911408

500W 2-zone matrix amplifier

Built-in media player

100V line

24V DC

Compatible with call-button console and wall-mounted panel

19" rack-mountable (2U)

Power output

2 x 500 W

TUNER

BLUETOOTH

USB

Coupure sono

Zones

AM-2500-2

Description

AM-2 Series: 500W 2-zone matrix amplifiers

They offer a complete solution for multi-zone calls and multi-source selection systems (1 source per zone max).

• 3 XLR microphone inputs with configurable DC 24V phantom power

• MIC 1 priority via Talk Over

• 2 auxiliary RCA inputs

• REC OUT outputs by zone RCA

• Dry contact for sound system cut-off

• FM tuner module and MP3, USB and SD player

• Bluetooth receiver module for streaming from your mobile phone, tablet or laptop

• Call microphone console MIC-2 and compatible wall panel PM-2 (RJ45)

• Output level meter for each channel

• Thermal, overload and short circuit protection

Type

Amplificateur préamplificateur
Power

2 x 500 W
Speaker outputs

2 canaux, 100V, 8 - 16 Ω
Power consumption

1200W
Signal-to-noise ratio

72 dB
Audio output level

0 dB / 600 Ω symétrique
Alimentation

AC 230 V – 50 / 60 Hz
Distorsion harmonique totale

0,5 %
Bande passante

60 Hz – 15 000 Hz (± 3 dB)
Protection et refroidissement

Ventilateur, Protection thermique, surcharge et court-circuit
Réglages tonalité

Entrée : Aigus : 12 kHz / Med: 2,5 kHz / Graves : 80 Hz (+15 dB) - Sortie : Aigus: 10 kHz / graves: 100 Hz (+15 dB)
Entrées / Sensibilité

MIC/LINE 1-3 : 60 dB – 16 dB / 20 KΩ Symétrique LINE 1 : 20 dB + dB / 20 KΩ Symétrique 2 RJ45 : 0 dB / 600 Ω symétrique
Sources intégrées

MP3 / USB / SD / TUNER / BLUETOOTH
Dimensions (W × D × H)

484 x 395 x 88 mm (19” 1U)
Weight

13,7 kg
