Mini amplifier preamplifier 2 x 20W Class D

Name: Mini amplifier preamplifier 2 x 20W Class D
Brand: RONDSON
SKU: AM 2020

Reference : AM 2020

SKU : 02147

EAN13 : 3701567910531

2 x 20W stereo mini-amplifier preamplifier with class D technology

Power output

2 x 20W

Impédance

4 Ω / 8 Ω

Zones

AM 2020

AM 2020

Description

Description :

Stereo mini amplifier preamplifier, class D, 2 x 20 W.

It offers loudspeaker outputs in 4, 8 Ω in Low Impedance.

It works on a 24V DC power supply.

Compact size ideal for wall or desk mounting.

Features and specifications :

It is equipped with :

1 stereo output, 20 W (2 channels)
1 flanged output 40 W
2 MIC/LINE inputs switchable via phoenix connectors
2 unbalanced RCA auxiliary inputs
Left/right volume control
Volume control and Treble/Streble
Integrated limiter for silent and efficient operation with switch, suitable for input via laptop and iPhone
Thermal protection and short circuit
24V DC power adapter included

SPECIFICATIONS	AM 2020
Type	Mini Amplifier Preamplifier 2 x 20 W Class D stereo
Power supply	DC 24 V - Adapter 230 V
Speaker output	In low impedance 4 and 8 Ω
Inputs/Sensitivity	AUX 1-2: Asymmetrical RCA MIC: 350 mV / 10 000 Ω / Terminal block LINE: 5 mV / 600 Ω / Terminal block
Frequency Response	50 Hz – 16 000 Hz
Signal to Noise Ratio	85 dB
Total harmonic distortion	<0,5%
Protection and cooling	Thermal, overload and short-circuit protection
Dimensions (W x D x H)	230 x 115 x 56,5 mm
Weight	0,90 kg
