amplifier-preamplifier 10 zones 600W rackable

Reference : MZ-6000P
SKU : 02263
EAN13 : 8809267791384

amplifier-preamplifier 10 zones 600W rackable

Power output
Zones
Share

Description

Characteristics :

  • Mixing amplifier 600W (60W max per zone)
  • Gain volume control on inputs 1 to 3
  • Phantom power (+15V) on each microphone input
  • 1 RJ-45 socket for PTT-200
  • 1 RJ-45 socket for RM-2000
  • PRE OUT/AMP IN for connecting a power amplifier
  • LINE inputs 4 to 5 per RCA
  • Recording output via RCA
  • Tone settings for each available input
  • TEL/Paging call input
  • Chime (2 tones, 4 tones), siren
  • Slot for optional module :
  • (CDP-100MU, CDR-100RDSU, DMT-100-2, EM-600, TP-100RDS)
  • Contact for remote power supply
  • Digital message (DMT-100-2)
  • Broadcasting chimes and microphones
  • Extension up to 3 micro lecterns (RM-2000)
  • In an emergency situation, E/M automatic message (connection DMT-100-2, EM-600)
  • Priority selection switch for microphone 1,2,3
SPECIFICATIONS MZ-6000P
Type Mixer-amplifier
Output power 600 W

Output impedance

 16.7 Ω / 100V, 4 Ω

Consumption

 1520 W

Output area

 10 zones

Inputs 1-6

6 (MIC/LINE x 4, LINE x 2),

CH-1: PTT

Priority

1)PTT/MIC-1

2)Digital Message

3)TEL,CH2

4)CH-3-CH-6, PACK

Signal-to-noise ratio

 MIC > 70 dB LINE > 80 dB

Distortion Rate

 ≤ 1 % (1KHz)

Frequency Response

 -3dB (55Hz-16Khz)

Input sensitivity

MIC: -50dBu 5K Ω symmetrical

LINE : -10dBu 15K Ω asymmetrical

Power supply

 AC 220-230V – 50/60 Hz – DC 24 V

Dimensions

483 x 352 x 133 mm (3U)

Weight

 23 Kg

Product Details

  • Brand
  • Reference
    MZ-6000P
  • SKU
    02263
  • EAN13
    8809267791384
