bluetooth 240W Compact Amplifier

Name: bluetooth 240W Compact Amplifier
Brand: RONDSON
SKU: AM240UB-2

Reference : AM240UB-2

SKU : 02728

EAN13 : 3701567911491

240W power mixer-amplifier

Standard operation at 70V, 100V and 4 Ω for low impedance.

Operates on 230V - 50/60Hz mains.

Integrated tuner, USB and Bluetooth player

Power output

240 W

BLUETOOTH

Coupure sono

Zones

AM60UB-2 / AM120UB-2 / AM240UB-2

Download (403.84KB)

AM240UB-2

Download (962.07KB)

Description

Datasheet PDF

Features:

It is equipped with :

- AM/FM tuner and USB/SD/Bluetooth player
- 1 balanced XLR combo MIC input, including 2 switchable 15 V phantom power supplies

- Outputs on euroblock terminals for 70V and 100V or 8 Ω
- 1 AUX RCA input
- 1 RCA LINE output
- 1 individual volume control per input, bass and treble control

- Priority function (mute)
- Siren triggered by front panel on/off button - Thermal, overload and short-circuit protection

Options :

This amplifier can be racked with the following brackets:
- EQ-4000 : 1U bracket kit compatible with AMUB-2 - 19 " rack
- EQ-4500 : 1U bracket kit compatible with AMUB-2 - 19" half rack

equerres de fixations amplis

EQ-4000 equerre rack"

SPECIFICATIONS	AM 240UB
Type	Mixing amplifier 240 W
Integrated sources	TUNER / BLUETOOTH USB / SD / MP3 PLAYER
Power supply	AC 110V / 240V – 50 Hz - DC 24V
Speaker output	On-line 70 and 100V In low impedance 4 Ω
Output power	240WRMS
Frequency Response	80 Hz – 16 000 Hz
Signal to Noise Ratio	MIC:>60dB LINE:>70dB MEDIA PLAYER : > 60 dB
Consumption	400 W
Total harmonic distortion	<1%
Protection and cooling	Fan, Thermal protection, overload and short-circuit
Dimensions (W x D x H)	44x215x315 mm DEMIRACK
Weight	3 kg
