20-zone 500W preamplifier amplifier

Name: 20-zone 500W preamplifier amplifier
Brand: JD-MEDIA
SKU: S-5020D

Reference : S-5020D

SKU : 02659

EAN13 : 8809267791254

Class D amplifier-mixer, 500W, 20 zones on 100V line.

Zones

S-5020D

Download (2.81MB)

Description

- Automatic speed control with integrated ventilation
- Vumeter for output
- Output selection for each zone or all zones (20)
- MIC / LINE gain volume for inputs 1 to 4
- Phantom power (+15 V) for each MIC input
- Push to Talk connection for Mic PTT 200 (RJ45)
- 2-tone, 4-tone chime
- Siren function
- Source module slot (options)
CDP 100MU / CDR 100RDSU / DMT-100-2 / EM 600 / TP 100RDS
- Contact for power control
- Remote control :
RM-2000: 20-zone micro desk (RJ45) (up to 32 mic) DMT-100-2 :
digital message reader
Chime broadcast and microphone
- Recording output REC OUT
- PRE OUT output
- Super-priority message message control terminal
- The PTT input has priority over the siren.
- In the event of a power failure, when the power is restored,
the amplifier resumes operation under the same conditions
initial conditions
- Input circuit, overload and overvoltage protection
- Two power supply levels to limit power consumption
power consumption
If DMT-100-2 integrated, priority input E/M, Emergency
E/M emergency message

SPECIFICATIONS	S-5020D
Type	Amplificateur-mélangeur numérique
Output power	500W
Output impedance 100 V	100 V - 4 Ω
Power consumption	750 W
Output	20 zones
Inputs 1-5	5 (MIC/LINE x 3, LINE x 2), CH-1 : PTT
Priority	1) MIC/LINE 1 -4 5) REC OUT 2) LINE 5-6 3) TEL PAGING 4) PACK UNIT
Signal-to-noise ratio	MIC > 70 dB LINE > 80 dB
Distortion	≤ 1 % (1 kHz)
Bandwidth	55 – 16 000 Hz
Input sensitivity	MIC :-50 dBu 5 K Ω BAL, LINE :-10 dBu 15 K Ω BAL
Power supply	AC 230 V 50 Hz – DC 24 V
Dimensions (L x P x h)	430 x 352 x 380 mm (3U)
Weight	13,3kg
