60W 2-zone mixing amplifiers in 100V

Name: 60W 2-zone mixing amplifiers in 100V
Brand: SEGON PROFESSIONAL AUDIO
SKU: AME-60-2Z

Reference : AME-60-2Z

SKU : 02739

EAN13 : 3701567911941

5-zone amplifiers preamplifiers with MP3 CD, TUNER and USB audio source

60W 2-zone mixer amplifier

Multimedia player (Tuner / USB / SD / Bluetooth)

Remote control

100V line

24V DC

Power output

60 W

BLUETOOTH

Impédance

100V

Zones

Série AME-2Z

Download (2.02MB)

AME-60-2Z

Download (843.69KB)

Description

This mixer amplifier is available: 60W

2 adjustable zones

Standard operation at 100V (per zone) and 4-8-16 Ω and

70/100V (direct only). • They operate on 110/230V – 50/60 Hz mains power or DC24V.

Features :

They are equipped with:
• AM/FM tuner and USB/SD/Bluetooth player
• 2 balanced 6.35 MIC/LINE JACK inputs
• 1 Tel input with ultra-priority volume on all sources (AUX/MIC)

• 1 priority MIC XLR input
• 2 RCA LINE inputs
• 1 RCA LINE output
• 1 individual volume control per input, 1 master volume control
• Thermal, overload and short-circuit protection
• Siren activated by on/off button on front panel
• Bluetooth pairing: "BT6678" password: 1234
• Remote control

Product Details

Brand
Reference

AME-60-2Z
SKU

02739
EAN13

3701567911941

Data sheet

Type

Ampli-mélangeur avec tuner/MP3/USB/SD/BLUETOOTH
Output power

60 W RMS
Speaker outputs

4 - 8 -16 Ω / 70V – 100V
Power consumption

100 W
Signal-to-noise ratio

MIC : + 72 dB - LINE : + 85 dB
Alimentation

AC 110V/230 V – 50/60 Hz - DC 24V
Alimentation fantôme

+ 24 V commutable
Distorsion harmonique totale

0,5 %
Bande passante

60 Hz – 15 000 Hz (± 3 dB)
Protection et refroidissement

Ventilateur, Protection thermique, surcharge et court-circuit
Réglages tonalité

Graves : ± 10 dB à 100 Hz Aigus : ± 10 dB à 10 000 Hz
Dimensions (W × D × H)

320 x 210 x 90 mm
Weight

3,950 kg
