240W Power Amplifier with DC 24V

Name: 240W Power Amplifier with DC 24V
Brand: JD-MEDIA
SKU: PA 124 C

Reference : PA 124 C

SKU : 01091

EAN13 : 8809267792015

240W power amplifier

Online 100V

DC 24V

Power output

240 W

Impédance

100V

Zones

PA 124 C

Description

Product sheet in PDF format

Characteristics

• Automatic variable speed fan

• Surge protection

• Rackable 19" in 2U

• 100 Volt line only

• XLR input and output

• Power-up noise reduction circuit

• 24V power supply

FEATURES		PA 112 C	PA 124 C	PA 148 C
RMS output power		120 W	240 W	480 W
Output impedance		100 V (83.3 Ω)	100 V (41.7 Ω)	100 V (20.8 Ω)
Harmonic distortion		< 1% at 1 KHz
Power consumption		335 W	650 W	1380 W
Power consumption 230 V	25 V	0,7 A	1,4 A	3A
	50 V	1,1 A	2 A	4 A
	100 V	1,7 A	3,3 A	6,7 A
Input sensitivity/Impedance (PGM, PRIORITY)		+4dBu (1.23V) / 30 KΩ balanced
Bandwidth		34 Hz – 20,000 Hz -3dB
Signal-to-noise ratio		>100 dB
High Pass Filter		200 Hz / -3dB
Food		AC 230V / 50 Hz / DC 24 V
Dimensions (WxDxH)		483 x 375 x 88 mm (2U)
Weight		10.5 kg	12.5 kg	15.5 kg
