120W power amplifier in 100 volts DC 24V
8809267792008
01090
120W power amplifier
Online 100V
DC 24V
In Stock
Delivered within 48/72h
For professionals
To log inFor individuals
Contact usProduct sheet in PDF format
Characteristics
• Automatic variable speed fan
• Surge protection
• Rackable 19" in 2U
• 100 Volt line only
• XLR input and output
• Power-up noise reduction circuit
• 24V power supply
| FEATURES |
PA 112 C |
PA 124 C |
PA 148 C |
|
|
RMS output power |
120 W |
240 W |
480 W |
|
|
Output impedance |
100 V (83.3 Ω) |
100 V (41.7 Ω) |
100 V (20.8 Ω) |
|
|
Harmonic distortion |
< 1% at 1 KHz |
|||
|
Power consumption |
335 W |
650 W |
1380 W |
|
|
Power consumption 230 V |
25 V |
0,7 A |
1,4 A |
3A |
|
50 V |
1,1 A |
2 A |
4 A |
|
|
100 V |
1,7 A |
3,3 A |
6,7 A |
|
|
Input sensitivity/Impedance (PGM, PRIORITY) |
+4dBu (1.23V) / 30 KΩ balanced |
|||
|
Bandwidth |
34 Hz – 20,000 Hz -3dB |
|||
|
Signal-to-noise ratio |
>100 dB |
|||
|
High Pass Filter |
200 Hz / -3dB |
|||
|
Food |
AC 230V / 50 Hz / DC 24 V |
|||
|
Dimensions (WxDxH) |
483 x 375 x 88 mm (2U) |
|||
|
Weight |
10.5 kg |
12.5 kg |
15.5 kg |
|
