Magnetic Induction Loop Amplifier for 450 m2
8809267791483
02332
Magnetic Induction Loop Amplifier for public places with a surface area of 450 m2.
In Stock
Delivered within 48/72h
For professionals
To log inFor individuals
Contact usDescription :
This Magnetic Induction Loop Amplifiers offer assistance to the hearing impaired in public places such as multi-purpose halls, theatres, cinemas, churches, conference areas, etc...
Characteristics :
- Dynamic Compressor: High audio signal is compressed to protect the amplifier.
- Adjustment to compensate for bandwidth problems in highly metallic buildings
- 40V phantom powering possible for condenser microphone
- Alarm Trigger: In case of emergency, the message recorded in the SD Card is played back.
- Priority: setting the priority audio signal
- Rack-mountable amplifier at 19ʺ (integrated brackets)
- SD card (8 GB) included
| SPECIFICATIONS | LA-08 | LA-10 | LA-2000 |
| Type | Magnetic induction loop amplifiers | ||
| Power supply | AC 230 V / 50 - 60 Hz | ||
| Coverage | 450 m2 | 750 m2 | 200 m2 |
| Consumption | 140 VA | 195 VA | 150 VA |
| Inputs |
MIC 1 to 3: 1.5 mV, 6.8 kΩ Symmetrical LINE 1 to 2: 630 mV, 10 kΩ Symmetrical LINE 3: 630 mV, 4.7 kΩ Symmetrical |
||
| Total Harmonic Distortion |
0,1 % |
||
| Frequency Response |
50 Hz - 8 000 Hz |
||
| signal-to-noise ratio |
higher than 65 dB |
||
| Loop current |
8 A |
10 A | 6 A |
| Loop Impedance |
0,5 - 2 Ω |
||
| Loop output | Terminal block | ||
| Headphone output |
180 mV (32 Ω) |
||
| Phantom power supply |
40 V |
||
| Dimensions (W x D x H) |
483 x 275 x 88 mm |
||
| Weight |
6,5 kg |
||
