Reader Recorder Module 8 pre-recorded messages

Name: Reader Recorder Module 8 pre-recorded messages
Brand: RONDSON
SKU: DMT-8M+

Reference : DMT-8M+

SKU : 02781

EAN13 : 370156791251

Player Recorder 8 audio messages

Mini USB PC Connection

DC 24V

USB

DMT-8M+

Download (884.46KB)

DMT-8M+

Download (920.46KB)

Description

Description :

The DMT-8M player offers the possibility to broadcast and record 8 audio messages.
Used to play information and evacuation messages to an audience.
It operates on 24V DC power supply.

Features :

Compatible player in WAV, VMA, MP3 format.
256 MB Memory
Mini USB port to play and rename audio files for updates (PC connection)
Common messages 1 to 4 (front panel) with the same priorities
Messages A-D (rear panel on euroblock terminal block) have priority over 1-4, the priority is as follows A˃B˃C˃D=1=2=3=4
Player mode: Play & Repeat
Mic & Line input on XLR/JACK socket with VOX Dip Switch, Mic/Line, phantom
Recording mode: messages 1,2,3,4 can be recorded directly on the back panel.
Vumeter for output and recording
Standard rack 19ʺ 1 U

SPECIFICATIONS	DMT-8M
Type	FM / CD / USB / SD / MP3 Tuner Player
Inputs	USB port / SD / MMC support
Phantom powering	DC 24 V / DIP SWITCH
Frequency Response	100 Hz – 20 000 Hz / -3dB/+3dB
Total harmonic distortion	< 0,05 %
Signal-to-noise ratio	Mic : – 65dBu / LINE : -75dBu
Reader	WAV, VMA, MP3
Recorder	Microphone and LINE recording
Inputs	+4dBV symmetrical / 500Ω 0dBV symmetrical / 1kΩ
Power supply	DC 24 V
Dimensions (W x D x H)	482 x 100 x 44 mm
Weight	2,3 kg
