19" flight case with wheels from 12U to 20U
19" flight case with wheels available in 4 sizes from 12U to 20U:
Reference: R12U - Code: 00622
Reference: R16U - Code: 00623
Reference: R18U - Code: 00631
Reference: R20U - Code: 00918
In Stock
Delivered within 48/72h
For professionals
To log inFor individuals
Contact us- With vertical profiles for 19" (483 mm) standard units.
- Multi-ply plywood, 9 mm thick, black plastic laminate finish, aluminium corner protectors, corner reinforcements and fittings.
- Butterfly locks and recessed handles for all models.
- The 12 to 20 U models are equipped with 4 Ø 100 mm castors, 2 of which have brakes. The 18U flight case (supplied with 2 tiltable mounting rails) has the particularity of being able to accommodate 19" equipment placed on top, such as a mixer for example.
- Supplied with M6 captive nuts, M6 x 15 mm Phillips head screws and plastic washers.
- Usable depth: 550 mm maximum (from 12 to 20 U)
| SPECIFICATIONS | DIMENSIONS W X D X H (MM) | SUPPLIED ACCESSORIES | REF | CODE |
| Standard flight cases (without wheels) | ||||
| Flight case 4 U | 545 x 687 x 240 | 8 screws (for 2 units) | R4UE-18 | 02037 |
| Flight case 8 U | 545 x 687 x 415 | 16 screws (for 4 units) | R8UE-18 | 02038 |
| Flight cases on wheels | ||||
| Flight case 12 U | 545 x 687 x 740 | 24 screws (for 6 units) | R12U | 00622 |
| Flight case 16 U | 545 x 687 x 920 | 32 screws (for 8 units) | R16U | 00623 |
| Flight case 18 U** | 545 x 687 x 1220 | 36 screws (for 9 units) | R18U | 00631 |
| Flight case 20 U | 545 x 687 x 1100 | 40 screws (for 10 units) | R20U | 00918 |
