6-zone preamplifier with message reader/recorder

Name: 6-zone preamplifier with message reader/recorder
Brand: RONDSON
SKU: T-6000

Reference : T-6000

SKU : 02142

EAN13 : 3701567901676

T-6000

Description

Characteristics :

6-zone preamplifier designed for multi-zone calls and multi-source selection system
Built-in microphone and recorder for easy voice message recording and storage
Direct selection of the 3 audio sources
selection button and display of the status of the 6 selection zones
6 T-6000A call stations connected to the T-6000 via RJ45 socket for remote control and announcement
XLR microphone input with phantom power and gain control
3 auxiliary inputs for cassette, CD and tuner
Chime, volume control and remote release
3 voice messages broadcast in continuous mode
3 outputs: music / speech and music / calls
6 line outputs for power amplifier
Volume control for microphone, music, master, recording and playing messages, as well as for bass / treble
Displays the selected zone, recording status, power and output level.
4 priority levels from highest to lowest: Zone call station, chime, pre-recorded message

How to use it :

SPECIFICATIONS	T-6000
CONSOLE INPUT
Sensitivity	-50/2dB 2,5/500mV
Signal to Noise Ratio	>68 dB
Frequency Response	100 – 17000 Hz (+1,-3dB)
MICROPHONE INPUT
Sensitivity	-50/2dB 2,5/500mV
Signal to Noise Ratio	>68 dB
Frequency Response	100 – 17000 Hz (-3dB)
Phantom power supply	+48V
3 AUXILIARY INPUTS
Inputs/ Sensitivity	Tuner and cassette : 200mV/47 Ω CD : 500mV/47 Ω
Signal to Noise Ratio	>90 dB
Frequency Response	40 – 20 000 Hz (+3, -3dB)
CONTROL
Bass / treble settings	Bass: ± 12 dB to 100 Hz Treble: ± 12 dB to 10 000 Hz
Carillon	2 configurable priority and BGM tones
Distorsion	>0,1%
STATE OF OPERATION
Power supply	220V/50Hz & DC 24V
Dimensions (W x D x H)	484 x 322 x 88 mm
Weight	6,5 Kg
